Got mine in the mail and went home right away to put them on. Took me about an hour and was fairly easy once I figured out how to do it. I could probably do it in about 30 min now. This is only for a GLS with no foglights so your experience may differ if you have fogs…

Step 1: Unplug the wiring harness on the Driver’s side and plug it into the SR harness. Plug the SR harness into the headlight housing. I had to cut away some of the plastic cover over the wires so it would bend down easier. I left the black ziptie on the DRL wires because it would reach without undoing all the wire..

Step 2: With a small phillips screwdriver, remove the two small plastic screw/fasteners that hold the front splash shield to the bottom of the bumper:

Step 3: Pull the splash shield out from under the lip of the bumper and pull it back, you don’t need to remove it.

Step 4: Remove the phillips screw from the bottom corner of the plastic foglight filler piece. I didn’t remove all the screws, I only took the corner one out and pushed in on the cover to slide the wires in. You do not have to remove the whole foglight plastic cover.

Step 5: Remove the backing on the adhesive tape on the outer parts of the DRL. Peel back the corner of the long piece on top of the DRL and fold it toward the front.

Step 6: (Clean the whole contact area thoroughly on the bumper, using rubbing alcohol and let dry first). Then fit the light in the area and press the corners in. Slowly pull out the "tab" you folded and pull out the red backing of the tape while mounted on the car. Press firmly on the lights for a few seconds to bond the tape. If you remove the whole long piece of the backing before you put it on the car, if you stick it on crooked, you won’t be able to take it off.

Step 7: Connect the red and black wires and make sure they click and lock.

Step 8: Put the screw back in the foglight cover and put the nylon fasteners back into the splash shield.

Here are some daylight pics, night pics to come when it gets dark:

We found this practical information from hyundai-forums.com and to shop car LED, please visit us at www.LEDoption.com, the affordable car LED store.

Introducing the LEDoption.com’s 1 pair super bright 18-SMD 3-Emitter 5050 chips 1156 LED light bulbs. This kind of 18-SMD 3-Emitter 5050 chips 1156 LED bulbs are available in the following colors: Xenon White, Ultra Blue, Brilliant Red and Amber Yellow.

A light-emitting diode (LED) is a semiconductor light source which is commonly used for automotive such as on Audi for daytime running lights, BMW for LED tail lights and Lexus for LED license plate lights; also widely appears on electronics such as cell phone for background lighting, flash lighting, even household for example display panels and Television. Overall, the most places the LEDs are used as a new lighting source to replace the traditional incandescent lamps and halogen light bulbs.

Surface mount technology (SMT) is a method for constructing electronic circuits in which the components (surface-mounted components/devices) are mounted directly onto the surface of printed circuit boards (PCBs). An electronic device so made is called a surface mount device (SMD). By using this kind of SMD technology for LED lights makes it possible to have many different varieties of designs, configurations, etc.

There are many different kind of SMD LED chips on the market such as 5050 SMD, 1210 (3528) SMD, 0603 SMD and 3020 SMD, the numerical numbers are essentially measurement of the dimensions of the SMD LED size by millimeter.

This particular kind of BA15s LED bulbs have 3 pieces 5050 type SMD LED light on the top and 3 pieces 5050 SMD LED lights on each side to make up this total 18 pieces 360 degree shinning 1156 LED bulbs. The size of this LED bulb is measured at 0.6″ for diameter and 2″ for length.

General speaking, this type of 1156 LED bulbs can replace 1073 1093 1129 1141 filament light bulbs, and will also replace the following light bulbs: 1159 1259 1459 1619 1651 1680 3496 5007 5008 7506.

Below are the pictures showing all four colors we carry for this kind of BA15s LED bulbs, you can click on the LED bulb picture to enlarge.

Finally, there are some information about the stock 1156 type incandescent light bulbs, thanks for DONSBULBS for the specifications.

The stock 1156 bulbs’ voltage is 12.8V, with current is measured at 2.1 AMP with total wattage at 26.9W. The average lifespan for the 1156 incandescent bulb is 1200 working hours, but our 7506 1156 LED bulbs in comparison is ranging from 5,000 up to 50,000 working hours.



Shop the most affordable car LED lights from LEDoption.com, the 12V LED outlet store.

• LEDoption Facebook

• LEDoption Twitter

Introducing LEDoption.com’s 1W BA9 bayonet High Power LED light bulbs. This type of BA9 bayonet LED light bulbs are available in the following colors: Xenon White and Ultra Blue.

A light-emitting diode (LED) is a semiconductor light source which is commonly used for automotive such as on Audi for daytime running lights, BMW for LED tail lights and Lexus for LED license plate lights; also widely appears on electronics such as cell phone for background lighting, flash lighting, even household for example display panels and TV. Overall, LEDs are commonly used as a new lighting source to replace the traditional incandescent lamps and halogen light bulbs.

High power light-emitting diodes (LEDs) are likely to replace other technologies such as incandescent and fluorescent bulbs in signaling, solid state lighting, and vehicle headlights because they save energy and extend the light’s lifetime. LEDs bulbs are anywhere from 500 milliwatts to 10 watts. Some of the electricity in an LED becomes heat rather than light. If the heat is not removed, the LEDs run at high temperatures, which not only lowers their efficiency, but also makes the LED more dangerous and less reliable. Thus, thermal management of high power LEDs is a crucial area of research and development.

There are many different kind of High Power BA9 LED chips on the market such as 64111, H6W, 1895, 53, 57, 182, 3886X, the numerical numbers are essentially measurement of the dimensions of the High Power LED size by millimeter.

This particular kind of BA9 LED bulbs are High Power LED lights on the top. The size of this LED bulb is measured at 0.56" for diameter and 1.09" for length.

General speaking, this type of BA9s Bayonet LED light bulbs can replace 64111, H6W, 1895, 53, 57, 182, 3886X, BA9, BA9s light bulbs.

Below are the pictures showing all two colors we carry for this kind of High Power BA9 64111 LED, you can click on the LED bulb picture to enlarge.

Thanks to DONSBULBS for the specifications for this BA9 Bayonet style bulb.

The stock BA9s bulbs’ voltage is 12V, with current is measured at 0.417 AMP with total wattage at 5W. Because of this bulb is at 5W, therefore it is also known as H5W. The average lifespan for the incandescent BA9s bulb is 200 working hours, but our BA9 LED bulbs in comparison has lifespan ranging from 2,000 to 20,000 working hours.
